Communications WPAN (Bluetooth Support) Bluetooth 4.0 WWAN radio type Worldwide: HSPA+: 900/2100/850/1900 MHz , EDGE/GPRS/GSM: 850/900/1800/1900 MHz Americas: LTE 1900/1700/850/700 MHz (FDD2, 4, 5, 17) HSPA+ 850/1900/1700/2100/900 MHz EDGE/GPRS/GSM: 850/900/1800/1900 MHz North America: LTE 700MHz (FDD13), EvDO 850/1900, CDMA 850/1900 (Verizon only*) Integrated GPS Integrated, Autonomous, Assisted-GPS (A-GPS), GLONASS WLAN Tri-mode IEEE® 802.11a/b/g/n Individual data rates supported 802.11a - up to 150 Mbps; 802.11b/g - up to 72.2 Mbps; 802.11n @ 2.4 GHz up to 72 Mbps; 802.11n @ 5 GHz up to 150 Mbps Security WEP (40 or 104 bit); WPA/WPA2 Personal; WPA/WPA2 Enterprise — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, TKIP, AES Performance Characteristics Operating system (OS) Android 4.1.2 Data capture options barcode Scanning: Integrated 1-D* linear imager; optional RS507 Bluetooth ring-style imager Camera: Autofocus 8 MP with user-controllable flash; supports integrated 1-D/2-D barcode capture Camera/Imager Exit Windows: Corning Gorilla Glass 2 NFC: Peer-to-peer, card reader, card emulation Memory 1 GB RAM / 8 GB Flash MLC Processor (CPU) 1.5 GHz dual core processor Interfaces USB 2.0 High Speed (host and client), WLAN, WWAN and Bluetooth Physical Characteristics Expansion slot User accessible 32GB microSD slot with SD HC support Voice, Speech and Audio Two front-facing speakers; dual noise-cancelling microphones; high-quality speaker phone; 3.5mm headset jack; Bluetooth wireless headset support Notification Vibrate and audible tone Touch panel Dual mode capacitive touch with stylus or bare or gloved fingertip input (conductive stylus sold separately) Interactive Sensor Technology Ambient Light Sensor: Automatically adjusts display backlight to maximize power efficiency Proximity Sensor: Automatically detects when the user places the handset against head during a phone call to disable display output and touch input Keypad options On-screen keypad Display type Blanview® LCD display, 4.3 in. WVGA, exceptional low power consumption, exceptionally bright image with 700 NITs, 3% transflective, Corning Gorilla Glass 2 Weight With standard battery: 7.8 oz./220 g Dimensions (HxWxD) With standard battery: 5.4 in. L x 2.7 in. W x 0.63 in. D / 137 mm L x 69 mm W x 15.9 mm D Power Battery Standard Battery: Replaceable and rechargeable Lithium Ion, 2940 mAh Extended Battery: Replaceable and rechargeable Lithium Ion, 1.5x: 4410 mAh Regulatory Specifications LED Safety EN 62471 WWAN Global: 3GPP TS 51.010, 3GPP TS 34.121, 3GPP TS36.521, 3GPP TS 34.123, 3GPP TS36.523, GCF and PTCRB approved USA: FCC Part 22, Part 24 Canada: RSS-132, RSS-133, 139 EU: EN301 511, EN301 908 Australia: AS/ACIF S042.1, 3 & 4 WLAN USA: FCC Part 15.247, 15.407, 15.225 Canada: RSS-210 EU: EN 300 328, EN 301 893, EN 302 291 Australia: AS/NZS 4268 Bluetooth/NFC USA: FCC Part 15.247, 15.407, 15.225 Canada: RSS-210 EU: EN 300 328, EN 301 893, EN 302 291 Australia: AS/NZS 4268 RF exposure US: FCC Part 2, FCC OET Bulletin 65c; Canada: RSS 102 Issue 4; EU: EN 50360; EN 50566; EN 62479; EN 62311; Australia: Radiocommunications Standard 2003 Environmental RoHS/WEEE compliant, EN 50581 Electrical safety UL 60950-1, EN 60950-1, IEC 60950-1, CAN/CSA-C22.2 No. 60950-1-07 EMI/RFI USA: FCC Part 15, Class B Canada: ICES-003 Class B EU: EN55022 Class B, EN 55024, EN 301 489-1, EN 301 489-3, EN 301 489-7, EN 301 489-17, EN 301 489-24, EN 60601-1-2, EN 50121-3-2, EN 50121-4 Australia: AS/NZS CISPR 22 User Environment Tumble specifications 300 1.6 ft//0.5 m tumbles; with protective boot 1000 1.6 ft/0.5 m tumbles meets and exceeds IEC tumble specifications Environmental sealing IP67, meets IEC specifications Thermal shock -40°F to 158°F/-40°C to 70°C rapid transition Shock/Vibration Vibration: MIL-STD 810G, 2Gs peak, 5Hz to 2kHz, 1 hour per axis; .04gˆ2/Hz, 20Hz to 2kHz, 1 hour per axis Humidity 5% to 85% non-condensing Drop specification 4 ft./1.2 m drop to plywood per MIL-STD 810G; With protective boot: 5 ft./1.5m to concrete at room temperature Storage temperature -40°F to 158°F/-40°C to 70°C Operating temperature 14°F to 122°F/-10°C to 50°C

Communications WPAN (Bluetooth Support) Bluetooth 4.0 WWAN radio type Worldwide: HSPA+: 900/2100/850/1900 MHz , EDGE/GPRS/GSM: 850/900/1800/1900 MHz Americas: LTE 1900/1700/850/700 MHz (FDD2, 4, 5, 17) HSPA+ 850/1900/1700/2100/900 MHz EDGE/GPRS/GSM: 850/900/1800/1900 MHz North America: LTE 700MHz (FDD13), EvDO 850/1900, CDMA 850/1900 (Verizon only*) Integrated GPS Integrated, Autonomous, Assisted-GPS (A-GPS), GLONASS WLAN Tri-mode IEEE® 802.11a/b/g/n Individual data rates supported 802.11a - up to 150 Mbps; 802.11b/g - up to 72.2 Mbps; 802.11n @ 2.4 GHz up to 72 Mbps; 802.11n @ 5 GHz up to 150 Mbps Security WEP (40 or 104 bit); WPA/WPA2 Personal; WPA/WPA2 Enterprise — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, TKIP, AES Performance Characteristics Operating system (OS) Android 4.1.2 Data capture options barcode Scanning: Integrated 1-D* linear imager; optional RS507 Bluetooth ring-style imager Camera: Autofocus 8 MP with user-controllable flash; supports integrated 1-D/2-D barcode capture Camera/Imager Exit Windows: Corning Gorilla Glass 2 NFC: Peer-to-peer, card reader, card emulation Memory 1 GB RAM / 8 GB Flash MLC Processor (CPU) 1.5 GHz dual core processor Interfaces USB 2.0 High Speed (host and client), WLAN, WWAN and Bluetooth Physical Characteristics Expansion slot User accessible 32GB microSD slot with SD HC support Voice, Speech and Audio Two front-facing speakers; dual noise-cancelling microphones; high-quality speaker phone; 3.5mm headset jack; Bluetooth wireless headset support Notification Vibrate and audible tone Touch panel Dual mode capacitive touch with stylus or bare or gloved fingertip input (conductive stylus sold separately) Interactive Sensor Technology Ambient Light Sensor: Automatically adjusts display backlight to maximize power efficiency Proximity Sensor: Automatically detects when the user places the handset against head during a phone call to disable display output and touch input Keypad options On-screen keypad Display type Blanview® LCD display, 4.3 in. WVGA, exceptional low power consumption, exceptionally bright image with 700 NITs, 3% transflective, Corning Gorilla Glass 2 Weight With standard battery: 7.8 oz./220 g Dimensions (HxWxD) With standard battery: 5.4 in. L x 2.7 in. W x 0.63 in. D / 137 mm L x 69 mm W x 15.9 mm D Power Battery Standard Battery: Replaceable and rechargeable Lithium Ion, 2940 mAh Extended Battery: Replaceable and rechargeable Lithium Ion, 1.5x: 4410 mAh Regulatory Specifications LED Safety EN 62471 WWAN Global: 3GPP TS 51.010, 3GPP TS 34.121, 3GPP TS36.521, 3GPP TS 34.123, 3GPP TS36.523, GCF and PTCRB approved USA: FCC Part 22, Part 24 Canada: RSS-132, RSS-133, 139 EU: EN301 511, EN301 908 Australia: AS/ACIF S042.1, 3 & 4 WLAN USA: FCC Part 15.247, 15.407, 15.225 Canada: RSS-210 EU: EN 300 328, EN 301 893, EN 302 291 Australia: AS/NZS 4268 Bluetooth/NFC USA: FCC Part 15.247, 15.407, 15.225 Canada: RSS-210 EU: EN 300 328, EN 301 893, EN 302 291 Australia: AS/NZS 4268 RF exposure US: FCC Part 2, FCC OET Bulletin 65c; Canada: RSS 102 Issue 4; EU: EN 50360; EN 50566; EN 62479; EN 62311; Australia: Radiocommunications Standard 2003 Environmental RoHS/WEEE compliant, EN 50581 Electrical safety UL 60950-1, EN 60950-1, IEC 60950-1, CAN/CSA-C22.2 No. 60950-1-07 EMI/RFI USA: FCC Part 15, Class B Canada: ICES-003 Class B EU: EN55022 Class B, EN 55024, EN 301 489-1, EN 301 489-3, EN 301 489-7, EN 301 489-17, EN 301 489-24, EN 60601-1-2, EN 50121-3-2, EN 50121-4 Australia: AS/NZS CISPR 22 User Environment Tumble specifications 300 1.6 ft//0.5 m tumbles; with protective boot 1000 1.6 ft/0.5 m tumbles meets and exceeds IEC tumble specifications Environmental sealing IP67, meets IEC specifications Thermal shock -40°F to 158°F/-40°C to 70°C rapid transition Shock/Vibration Vibration: MIL-STD 810G, 2Gs peak, 5Hz to 2kHz, 1 hour per axis; .04gˆ2/Hz, 20Hz to 2kHz, 1 hour per axis Humidity 5% to 85% non-condensing Drop specification 4 ft./1.2 m drop to plywood per MIL-STD 810G; With protective boot: 5 ft./1.5m to concrete at room temperature Storage temperature -40°F to 158°F/-40°C to 70°C Operating temperature 14°F to 122°F/-10°C to 50°C

Datasheet
